Copper Tape Screened PVC Control Cable | 450/ 750 V Cu Conductor PVC Insulated and Sheathed

Copper Tape Screened PVC Control Cable | 450/ 750 V Cu Conductor PVC Insulated and Sheathed image

Get a Quote Email to us

Brand Name :
Chengtiantai cable

Model Number :
KVVP2

Certification :
CCC, ISO

Place of Origin :
Shenzhen, China (mainland)

MOQ :
1000 m

Price :
On request

Payment Terms :
L/C, T/T

Delivery Time :
7/ 15 Working days

Packaging Details :
Steel wooden drum

Rated Voltage :
450/750 Volts

Conductor :
bare Copper class 2

Number of cores :
2 to 61 cores

Insulation :
PVC Compound

Screen :
copper Tape

Sheath :
PVC Compound

Copper Conductors PVC Insulated Copper Tape screened and PVC Sheathed Control Cable

Construction 450/750 V, PVC insulated, Copper conductors, PVC bedded, collective copper tape screened and PVC sheathed.

Copper tape screened multicore PVC cable for protection against electrical interference. Suitable for as interconnecting cables for measurement, control or regulation in control equipment for assembly and production lines, conveyors, and computer units.

⊙ STANDARDS/REFERENCES:

International: IEC 60227-5
National: GB/T 9330-2008

⊙ CONSTRUCTION CHARACTERISTICS
CONDUCTOR:

bear copper class 1, class 2 (stranded conductors) according to IEC 60228

INSULATION:

PVC (Polyvinyl Chloride)
Core Identification :cores with continuous white numbering

TWISTED

Cores twisted in layers

WRAPPING:

Polyester tape (PET) wrapping

SCREEN

copper Tape

SHEATH:

PVC (Polyvinyl Chloride)

Sheath color: black
⊙ DIMENSIONAL CHARACTERISTICS
[Number of cores ]: 2, 3, 4, 5, 7, 8, 10, 12, 14, 16, 19, 24, 27, 30, 37, 44, 48, 52, 61
[Conductor size] : 1.0, 1.5, 2.5, 4, 6, 10 mm²
⊙ TECHNICAL DATA
[Rated voltage (Uo/U) ]: 450/750V
[Test voltage ]:3000 V
⊙ USAGE CHARACTERISTICS
[Maximum operating temperature] : 70 ℃
[Short-circuit max conductor temperature ( duration up to 5s ) ]:160 ℃
[Temperature range]: -5 to +70 ℃
⊙ INSTALLATION CONDITION
[Installation temperature ]: 5 ℃
[Minimum bending radius ]: 12 X cable diameter
[Recommended maximum tensile stress]: 50 N/mm²

Cable Dimensions

Number of cores x Cross-sec.	Outer diameter	Weight approx.	Base Unit	Price (base price)
2 x 1	11.1	148	m	Price on request
2 x 1.5	12.2	186	m	Price on request
2 x 2.5	13.1	236	m	Price on request
2 x 4	14.8	406	m	Price on request
2 x 6	16.3	410	m	Price on request
3 x 1	11.4	158	m	Price on request
3 x 1.5	12.6	208	m	Price on request
3 x 2.5	13.8	288	m	Price on request
3 x 4	15.8	406	m	Price on request
3 x 6	17.3	547	m	Price on request
4 x 1	10.3	198	m	Price on request
4 x 1.5	11.3	233	m	Price on request
4 x 2.5	11.7	375	m	Price on request
4 x 4	14.3	493	m	Price on request
4 x 6	15.7	602	m	Price on request
5 x 1	10.7	232	m	Price on request
5 x 1.5	12.7	299	m	Price on request
5 x 2.5	14.3	448	m	Price on request
5 x 4	15.4	562	m	Price on request
5 x 6	16.9	708	m	Price on request
7 x 1	11.4	259	m	Price on request
7 x 1.5	13.5	378	m	Price on request
7 x 2.5	15.3	520	m	Price on request
7 x 4	16.5	679	m	Price on request
7 x 6	18.3	892	m	Price on request
8 x 1	12.7	286	m	Price on request
8 x 1.5	14.4	442	m	Price on request
8 x 2.5	16.3	598	m	Price on request
8 x 4	18	760	m	Price on request
8 x 6	20	1002	m	Price on request
10 x 1	14.3	438	m	Price on request
10 x 1.5	16.3	520	m	Price on request
10 x 2.5	19.1	726	m	Price on request
10 x 4	20.7	941	m	Price on request
10 x 6	22.7	1208	m	Price on request
12 x 1	14.7	470	m	Price on request
12 x 1.5	16.4	596	m	Price on request
12 x 2.5	19.9	816	m	Price on request
12 x 4	21.3	1096	m	Price on request
12 x 6	23.8	1403	m	Price on request
14 x 1	15.3	518	m	Price on request
14 x 1.5	17.5	672	m	Price on request
14 x 2.5	20.5	900	m	Price on request
14 x 4	22.3	1149	m	Price on request
14 x 6	24.9	1434	m	Price on request
16 x 1	15.9	560	m	Price on request
16 x 1.5	18.3	729	m	Price on request
16 x 2.5	21.58	984	m	Price on request
19 x 1	16.6	629	m	Price on request
19 x 1.5	19.5	808	m	Price on request
19 x 2.5	22.5	1103	m	Price on request
24 x 1	19.3	760	m	Price on request
24 x 1.5	22.3	985	m	Price on request
24 x 2.5	25.9	1360	m	Price on request
27 x 1	19.7	805	m	Price on request
27 x 1.5	22.7	1047	m	Price on request
27 x 2.5	26.4	1463	m	Price on request
30 x 1	20.3	854	m	Price on request
30 x 1.5	23.5	1204	m	Price on request
30 x 2.5	27.3	1650	m	Price on request
37 x 1	21.6	997	m	Price on request
37 x 1.5	25.1	1315	m	Price on request
37 x 2.5	29.9	1900	m	Price on request
44 x 1	23.96	1168	m	Price on request
44 x 1.5	27.9	1525	m	Price on request
44 x 2.5	33.3	2294	m	Price on request
48 x 1	24.3	1220	m	Price on request
48 x 1.5	28.3	1620	m	Price on request
48 x 2.5	38.5	2347	m	Price on request
52 x 1	28.5	1285	m	Price on request
52 x 1.5	29.7	1730	m	Price on request
52 x 2.5	35.1	2610	m	Price on request
61 x 1	27.2	1450	m	Price on request
61 x 1.5	31.3	2021	m	Price on request
61 x 2.5	37.1	3015	m	Price on request

* Weight and dimensional information is provided as an approximate guide only.

⊙ Payment terms

T/T, 30% deposit before production, 70% balance before delivery

⊙ Packaging & Delivery

* Standard delivery length: 100 m/ coil or 500 m per drum

Packaging details		Delivery

Steel Wooden Drums	Cable Drum In container	shipped in 15 days after payment

⊙ Cable Drum Data

CABLE DRUMS	D1=Flange Diameter(mm)	W=Useful Width (mm)	D2=Barrel Diameter(mm)
	1000	700	500
	1100	700	550
	1200	700	600
	1400	750	710
	1600	900	900
	1800	1120	1000
	2400	1150	1300

⊙ Delivery Port:


Port of Shenzhen	Port of Hongkong	Port of Guangzhou
