Shopping Mall Prefabricated Branch Cable High Performance Environmental Protection

Shopping Mall Prefabricated Branch Cable High Performance Environmental Protection image

Get a Quote Email to us

Brand Name :
HOLD-ONE

Certification :
CE/KEMA/CCC/TUV

Place of Origin :
China

MOQ :
500m

Price :
USD 1.15 to 12.5 /Meter

Payment Terms :
L/C, T/T, Western Union

Supply Ability :
100KM/ day

Delivery Time :
10-15 days

Packaging Details :
wooden drum ,drum size:1.25×1.25×0.75m, 20 ft container can load 12 packages

Color of insulation :
Red ,Black or according to customer’s requirment

Sample :
Free

Nominal Area of conductor :
6mm2 to 1200mm2

Test Voltage :
3.5KV/5min

Conductor Type :
Stranded Copper conductor(class2)

Standard :
IEC 60502-1,IEC60228

Main Market :
Indonesia

Shopping Mall Prefabricated Branch Cable High Performance Environmental Protection

Brief introduction

Prefabricated branch cable with rated voltage 0.6/1KV and is a new Kind of low voltage distribution products. The prefab style can decrease the labor intensity greatly, shorten work time, and reduce cost greatly.

Application

This cable is used for urban networks. It can be installed aerially, in conduit, on open trays and in underground ducts.

Construction

Plain annealed copper, XLPE insulation, unarmoured or aluminium wires armoured, PVC sheathed cable

Main technical performance:
Ac voltage test: (put it in water for 1 hour) : 3.5kv /5min.
Dc resistance test: according to iec 60502-1997 standard

Insulation resistance test: 20 ℃ when meet not less than 200 m Ω insulation resistance
125 times thermal cycling: tapping temperature is not more than 70 ℃
Conductor breaking force: not less than 80% of the main cable

We are a manufacture in this filed for many years, we can offer our customers cables with good quality and price.

We Sincerely welcome customers at home and abroad to negotiate and cooperate with us !!!
