Telecommunication Equipment 600V Low Smoke Halogen Free RRU Power Cable

 China Telecommunication Equipment 600V Low Smoke Halogen Free RRU Power Cable supplier

Telecommunication Equipment 600V Low Smoke Halogen Free RRU Power Cable image

Get a Quote Email to us

Model Number :RRU CABLE
Certification :IEC 60228 IEC60332
Place of Origin :Henan ,China
MOQ :1000meters
Conductor :Flexible copper or tinned copper
Insulated :Flame retardant Low Smoke Halogen Free Polyolefi
Colour :black and grey
Application :Industrial,Construction
Type :Low Voltage
Jacket :Flame retardant Low Smoke Halogen Free Polyolefin

600V Telecommunication Equipment Low Smoke Halogen Free RRU Power Cable





Cable Application

Halogen free, shielded and flexible connecting cable for use in telecom equipment where there are requirements for low inductance and good temperature resistance. Suitable in areas that require high electromagnetic compatibility. Grey jacket for indoor use. Black jacket is sunlight resistant, for outdoor use.

Cable Construction

Conductor:Stranded, annealed copper, tinned, flexible, according to IEC 60228, class 5. Three parallel cores to form a flat conductor.

Insulation:Flame retardant Low Smoke Halogen Free Polyolefin, black and grey.

Shield:AL/PE laminate together with braid of annealed and tinned copper wires + Al-polyester foil.

Sheath: Flame retardant Low Smoke Halogen Free Polyolefin, black and grey.

Other Properties:

Operating voltage : Max 600V

Operating temperature : Max 90ºC, dry

Fire resistance IEC 60332-3 cat C



Product No. Conductor Application Insulation Thickness (mm)

Insulation

Color

Sheath

Color

Sheath

Nominal

Size (mm)

TFL 492 322

2×2.5mm2

(14AWG)

Indoor 0.6

Grey and

Black

Grey 7.0×7.3
TFL 492 324

2×6mm2

(10AWG)

Indoor 0.7

Grey and

Black

Grey 9.5×9.5
TFL 492 324/0

2×6mm2

(10AWG)

Outdoor 0.7

Grey and

Black

Black

UV-stabilized

9.5×9.5
TFL 492 325

2×10mm2

(8AWG)

Indoor 0.7

Grey and

Black

Grey 10.5×11.5
TFL 492 325/0

2×10mm2

(8AWG)

Outdoor 0.7

Grey and

Black

Black

UV-stabilized

10.5×11.5
TFL 492 326/0

2×16mm2

(6AWG)

Outdoor 0.7

Grey and

Black

Black

UV-stabilized

11.8×13.6


We are China Telecommunication Equipment 600V Low Smoke Halogen Free RRU Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
