Underground 5 Core 70mm2 XLPE Insulated Lv Armoured Cable

 China Underground 5 Core 70mm2 XLPE Insulated Lv Armoured Cable supplier

Underground 5 Core 70mm2 XLPE Insulated Lv Armoured Cable image

Get a Quote Email to us

Model Number :LV Power Cable 5 cores
Place of Origin :Henan, China (Mainland)
MOQ :200 Meter/Me
Insulation Material :XLPE
Type :Low Voltage
Application :LV Electric Power Cables
Conductor Material :Copper
Jacket :PVC
Conductor :Cu
Core Number :5
Insulation :XLPE/PE/PVC
Dia :70mm2
Outer Sheath :PVC
Rated voltage :0.6/1KV
Certificate :ISO9001/ISO14001
Standard :IEC, BS, ICEA, CSA, NF, AS-NZS


XLPE insulated LV Power Cable For Underground 5 Core 70mm2 Armoured Cable

Product Description

 A five-core low-voltage cable has five core wires insulated from each other, and a plastic sheath or steel armor plus a plastic sheath that wraps the five core wires is outside.



LV Electric Power Cables are used for laying indoor, tunnel, underground, canal, water and seabed, etc.


Applicable Standard:

 We can produce according to standard IEC60502-1 , BS 5467, ICEA S-95-658, CSA C22.2 , NFC 33-210 /NFC 32-322, AS-NZS 5000.1,etc





Cu Conductor+Xlpe Insulation + PVC Inner sheath + PVC Outer Sheath





Five(5) core, XLPE Insulated Power Cable
Size Cable dia. Cable weight
None- Steel tape armored Steel wire armored None-armored Steel tape armored Steel wire armored
armored CU AL CU AL CU AL
mm2 mm kg/km
50 27.1 30.3 34.7 2562 1053 2916 1407 3854 2344
70 31.3 36.1 38.9 3528 1415 4294 2180 5009 2895








Packaging & Shipping



Company Information




Q1: Are you a manufacturer or a trade company?
A: We are cable manufacturer with 15 years production experience and more than 10 years export experience.
Q2: I do not know how to choose what I need. / I have not found the cable type and size I need on this page.
A: Please do not worry. Contact us and send us your requirements, we will help you to choose correct cable you need. If you have below information is better: Cable voltage, conductor material, Insulation and Outer sheath material, armor type. Otherwise you can provide us the cable installation environment, application requirements, etc.

Q3: What’s your MOQ?/ How long is your delivery time?
A: MOQ & Delivery time both according to different product, product size, production construction. Welcome to contact us for further communication. Anyway, we will try our best to support you!
Q4: What`s your quality guarantee and period.
A: We guarantee that all of our products are free from defects. We will take back any product that does not meet the agreed quality by both parties. Usually the guarantee period is 18 months after shipment and 12 months after installation, which is earlier .


Looking forward to cooperating with you.

We are China Underground 5 Core 70mm2 XLPE Insulated Lv Armoured Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
