Underground Xlpe Insulated Pvc Sheathed Cable 3 Core 3×4mm2

 China Underground Xlpe Insulated Pvc Sheathed Cable 3 Core 3×4mm2 supplier

Underground Xlpe Insulated Pvc Sheathed Cable 3 Core 3×4mm2 image

Get a Quote Email to us

Brand Name :HOLD-ONE
Certification :CE/IEC/KEMA/VDE
Place of Origin :China
MOQ :Negotiable
Price :Negotiable
Payment Terms :L/C, T/T
Supply Ability :100km per Month
Delivery Time :8-15 days
Packaging Details :Iron-wooden Drum or Whole Wooden Drum
Name :Xlpe Insulated Pvc Sheathed Cable
Conductor Material :Aluminium
standard :IEC 60502-1
Outer Sheath :PVC
Color :Customized
Core :3 Core

Underground Xlpe Insulated Pvc Sheathed Cable 3 Core 3×4mm2

The Xlpe Insulated Pvc Sheathed Cable is used primarily for overhead and distribution line, or to supply 120/220V aerial service for tem service at construction sites, as a service drop (power pole to service entrance) as a secondary cable (Pole to Pole), or street lighting.

Physical and Electrical Characteristics

No.cores x Insulation Sheath Outer Ø weight Current ratings in air 30℃ Current ratings buried 20℃
cross-sec. thickness thickness approx. approx.
Nominal
Phase Neutral value
mm² mm mm mm mm kg / km A A
3×4+1×2.5 0.7 0.7 1.8 12.7 277 37 47
3×6+1×4 0.7 0.7 1.8 13.9 363 47 60
3×10+1×6 0.7 0.7 1.8 16.1 527 64 81
3×16+1×10 0.7 0.7 1.8 18.6 766 85 106
3×25+1×16 0.9 0.7 1.8 22.2 1140 113 137
3×35+1×16 0.9 0.7 1.8 24.6 1475 139

164

Conductor type

Currently, copper (Cu) and aluminum (Al) are the main materials for XLPE conductors.

(1) Copper (Cu)
Copper (Cu) conductor has advanced electrical characteristics, processability and economic benefits. Therefore, they are used in most underground conductor materials. It is worth noting that the purity of electrolytic copper needs to reach 99.96%~99.86%.
(2) Aluminum (Al)
Since aluminum is about one-third lighter than copper, it is easier to handle. Its conductivity is about two-thirds of copper, but it is more economical. Due to these characteristics, Al is the most widely used material after copper.

Benefits of XLPE

Plastic insulation materials have the advantages of excellent insulation properties, easy wiring, connection and maintenance, so they are widely used in advanced countries. Due to the development of cross-linking technology, XLPE insulated cables can be applied to higher voltages. Recently, XLPE cables have completely replaced OF cables. The advantages of XLPE are its light weight, thermal characteristics, low wiring costs and low material costs.

We are China Underground Xlpe Insulated Pvc Sheathed Cable 3 Core 3×4mm2 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
